S/N

Item

Parameters

1

Stop Band Frequency

578 ~ 608MHz

2

Stop Band Attenuation

≥45dB (Typical: ≥50dB)

3

Pass Band Frequency

DC ~ 548MHz , 658 ~ 1500MHz

4

Pass Band Insertion Loss

≤1.0dB

5

Pass Band VSWR

≤1.5:1 @ 310 ~ 548MHz , 658 ~ 1500MHz

≤1.7:1 @ DC ~ 310MHz

6

Impedance

50 Ohms

7

Power Handling

10W Max.

8

Connectors

SMA-Female

9

Surface Finish

Painted Black
