| Technical Data Sheet | ||
| ● | Center Frequency (F0) | 916MHz |
| ● | Pass Band Frequency | 912～920MHz |
| ● | Pass Band Insertion Loss | ≤1.0dB |
| ● | Pass Band VSWR | ≤1.3:1 |
| ● | Stop Band Rejection | ≥40dB @ DC～880MHz ≥40dB @ 940～2000MHz |
| ● | Impedance | 50 ohms |
| ● | Power Handling | ≤20W |
| ● | Connectors | SMA-Female |
| ● | Surface Finish | Black Paint |
| Test Curve | ||
